Medicine Hat sits at roughly 690 metres above sea level, carved into the South Saskatchewan River valley where the 2015 seismic hazard update for southeastern Alberta quietly reshaped how we think about local ground response. It is not Vancouver or Montreal, but the combination of deep glacial till over Cretaceous shale—and the sharp topographic contrast of the coulees—means that bedrock shaking can amplify in ways that standard NBCC site classes alone do not capture. A seismic microzonation study translates regional hazard curves into site-specific ground motion parameters, mapping how shear wave velocity profiles, impedance contrasts, and basin-edge geometry modify shaking intensity across a single lot or an entire subdivision. In our experience working across the Cypress Hills region and the valley floor, what looks uniform on a surficial geology map can hide a two-class jump in amplification over less than a hundred metres. When a new school, healthcare facility, or mid-rise residential block is programmed on the valley benches, the structural design team needs more than a code-default spectrum—they need a microzonation that accounts for the real stratigraphy under Medicine Hat’s post-glacial landscape. That work routinely ties into the MASW survey for shear wave velocity profiling and, where liquefiable silts appear near the river, a parallel liquefaction assessment to screen for cyclic softening under the design earthquake.
Shaking in Medicine Hat is not just about magnitude and distance—it is about the three metres of stiff clay sitting over twenty metres of soft shale, and how that stack filters every frequency differently.
Our approach and scope
Local considerations
One thing we see repeatedly in Medicine Hat is that the standard site class D assumption—often adopted by default for glacial till—can be unconservative on the valley benches where a thin stiff crust overlies softer, deeply weathered shale. The impedance contrast between these two materials creates a resonance effect that amplifies short-period spectral accelerations, sometimes pushing Sa(0.2s) twenty to thirty percent above the code-specified value for site class D. The other local trap is the coulee geometry: narrow incised valleys can focus surface waves and generate differential motion between the crest and the toe of a slope, a condition that matters enormously when a building footprint straddles both. Ignoring these effects means a structural design that is either over-optimistic or needlessly expensive, neither of which sits well with a project budget or a building official reviewing the submission. The microzonation removes the guesswork, giving the structural team a defensible spectrum and the geotechnical engineer a clear picture of where ground improvement or foundation stiffening is actually warranted. In a city where the seismic hazard is moderate but the soil variability is high, skipping the site-specific study is a gamble that rarely pays off.
Reference standards
NBCC 2020 – National Building Code of Canada, seismic hazard provisions, CSA A23.3-19 – Design of concrete structures, seismic requirements, ASTM D7400 – Standard test methods for downhole seismic testing, ASTM D5777 – Standard guide for seismic refraction, ASTM D4428/D4428M – Standard test methods for crosshole seismic testing
Complementary services
MASW and Downhole Seismic Surveys
Multi-channel surface wave profiling and downhole velocity logging to measure the shear wave velocity profile, a mandatory input for any site response analysis. We deploy arrays adapted to the tight spaces of urban Medicine Hat lots, delivering Vs30 and Vs-depth curves calibrated against available borehole lithology.
Liquefaction Screening and Cyclic Softening Analysis
Focused assessment of saturated sandy silts and loose sands within the buried valley fill, using SPT or CPT data to evaluate the factor of safety against liquefaction under the design earthquake. Where residual settlement or lateral spreading could affect riverbank structures, we integrate the results into the microzonation framework.
Typical parameters
Common questions
What is the typical cost for a seismic microzonation study in Medicine Hat?
For a single-lot commercial or institutional project in the Medicine Hat area, a complete microzonation including field geophysics, site response modelling, and a signed engineering report typically ranges from CA$6,240 to CA$19,950. The spread depends on the number of measurement points, the depth to bedrock, and whether 2D effects need to be modelled for coulee-edge sites.
How does microzonation differ from the standard NBCC site classification?
The NBCC site classification—based on Vs30 or N60 averages—gives you one amplification factor per site class. Microzonation goes further: it models how your specific soil column filters the actual hazard spectrum for Medicine Hat, producing surface acceleration values at multiple periods and identifying whether short-period or long-period amplification dominates. It also maps spatial variation across a site, which a single site class cannot do.
What field data do you need to collect for a Medicine Hat microzonation?
The minimum dataset includes a measured shear wave velocity profile—from MASW, downhole, or crosshole testing—and a detailed lithologic log to define layer boundaries and material damping. We also collect ambient vibration recordings for HVSR analysis and, where the valley geometry is complex, we may run a small refraction line to map the bedrock surface. Existing borehole data from the area can supplement the program if properly logged.
How long does a microzonation study take from field work to final report?
For a typical Medicine Hat project, you can expect the field campaign to last two to four days depending on array sizes and site access. Data processing and site response modelling usually require another two to three weeks, and the final report with microzone maps and design spectra is delivered within four to five weeks from mobilization, assuming no weather delays or access restrictions.
